45 Ton Straddle Carrier en Pekín, China
Usado
Doubleclick to zoom in
Contacte al vendedor
para más fotos y información.
Especificaciones
- Condición
- usado
- Model
- 45 Ton Straddle carrier, Mobile Gantry, Container handler
- Lifting capacity(under spreader)(t)
- 45 ton, 45 tone, 45T straddle carrier gantry crane
- Span (m)
- 5m~40m
- Lifting height (m)
- 5m~18m
- Stack layers
- 2/3/4
- Container model
- 20′, 30′, 40′, 45′, 20ft, 40ft, 45ft, 20 feet, 40 feet, 45 feet
- Spreader rotating angle
- ±5°
- Travel speed (m/min)
- Full Load-20/90, Without Load-40/130, 30kph
- Crane turning degree
- Straight travel, oblique travel, 90° in-situ steering
- Max. wheel load (kn)
- 310
- Total rating (kw)
- 230
- Certification
- CE ISO UL SGS
- Control
- Driver Cabin Control / Wireless Remote Control
- Power supply
- AC, Electric, Diesel Engine, Electric-diesel Engine, Hybrid power
- Features
- Multi-functional, lighter operating weight, Low pressure on the ground, Equipped with specialized spreaders to lift standard-sized 20GP, 40GP, 45HQ containers and gas storage tanks.
- Application area
- Handling modular construction components, vessel assembly warehouse, machinery manufacturing workshop or outdoor storages, quay container transport, modular house building, tubbing handling, etc.
- Straddle carrier cost
- $110,000~$220,000
- Categoría
- Grupos electrógenos en China
- Subcategoría
- Straddle carrier
- ID de Anuncio
- 104148284
Descripción
The 45t straddle carrier is primarily designed to efficiently handle containers at sea ports terminals, rail yards and container depots.
Lifting capacity: 45 Ton(tonne)
Models: MG Gantry, Container handler
Travel speed: 50~130m/min(Empty load/Full load)
Hoisting capacity under spreader: 40T
Rotation angle of spreader: ±5 °
Wheel quantity: 3 wheels, 4 wheels straddle carrier
Power supply: Diesel generator / Electric / Lithium battery / Lithium iron phosphate battery(LFP)
Control method: Wireless radio remote control, driver cab control
45 ton straddle carrier supplier type: China manufacturer
45 ton straddle carrier price: $150,000~$200,000
